| 规格/机型 Specification/model | JSSGS-1 | JSSGS-2 | JSSGS-3 | JSSGS-4 | |
|---|---|---|---|---|---|
| 适用压铸机 DCM | 200T以下 Under 200T | 280-400T | 450-580T | 630-800T | |
| 升降行程安装面到 Ascending/descen ding stroke | 模组下喷嘴 Bottom nozzle | -620mm | -740mm | -940mm | -1100mm |
| 铜管未端 End of copper tube | -700mm | -820mm | -1040mm | -1200mm | |
| 双排喷头覆盖宽度动定模相同（选配） Nozzle head width (Option) | 360mm | 360+100mm | 460+100mm | 560+100mm | |
动定模喷嘴数（选配） Nozzle (Option) | 20psc | 28+8psc | 36+8psc | 44+8psc | |
| 喷头跨距（选配） Nozzles (Option) | 150mm | 215mm | 215mm | 245mm | |
| 铜管（固定模）喷雾（选配） Copper tubes(Fixed) (Option) | 19pcs(?6) | 21pcs(?6) | 24pcs(?6) | 24pcs(?6) | |
| 铜管（中间模）喷雾（选配） Copper tubes(Middle) (Option) | 18pcs (?6) | 20pcs (?6) | 23pcs (?6) | 23pcs (?6) | |
| 铜管（活动模）喷雾（选配） Copper tubes(Moving) (Option) | 19pcs (?6) | 21pcs (?6) | 24pcs (?6) | 24pcs (?6) | |
| 气压源 Compress air | 4-6kgf/cm2 | ||||
| 气压源接口 Compress air inlet | PT1 1/4" | PT1 1/2" | PT1 1/2" | PT1 1/2" *PT1" | |
| 离型剂 Release agent | 大于或等于气压≥Compress air | ||||
| 离型剂接口 Release agent inlet | PT1 1/2" | ||||
| 底座行程 Base unit stroke | 100mm | 200mm | 200mm | 300mm | |
| 升降电机功率 Ascend/descending motor capacity | 0.85KW | 1.3KW | 1.3KW | 1.8KW | |
| 底座电机功率 Base unit motor capacity | 250W | ||||
| 上升+下降时间 Ascend + descending time | 1.6S | 2.3S | 2.7S | 3.5S | |
| 主电柜电源 Power supplier(electric box) | 三相四线AC380V(A、B、C、PE) Three phase four wire AC380V(A、B、C、PE) | ||||
| 操作电源Power supplier | DC24V | ||||
| 离型剂喷雾时间Release agent spray time | 固定模 MAX9.9秒&活动模 MAX9.9秒 Fixed MAX 9.9s & Moving MAX 9.9s | ||||
| 离型剂调水量 Release agent adjustment water volume | 固定模及活动模皆可调整水量大小 Both fixed and movable can adjust the water volume | ||||
| 机器重量Net weight | 300kg | 450kg | 500kg | 600kg | |
| 机器外形尺寸（长*宽*高） Dimensions(L*W*H) | 900×530×1340 | 1120×550×1600 | 1150×650×1730 | 1270×740×1950 | |
