| 规格/机型 Specification/model | JSSB-2 | JSSB-4 | JSSB-6 | JSSB-8 | |
|---|---|---|---|---|---|
| 适用压铸机 DCM | 180-400T | 500-800T | 900-1250T | 1600T | |
| 升降行程安装面到 Ascending/Descending Stroke | 模组下喷嘴 Bottom Nozzle | -850mm | -1060mm | -1305mm | -1505mm |
| 模组喷头总长 Nozzle Head Width | 390+260mm | 520+130mm | 650+130mm | 650+130mm | |
| 固定（活动）模喷嘴总数 Total Nozzles | 24-40pcs | 32-40pcs | 40-48pcs | 40-48pcs | |
| 模组喷头（固定模）喷雾 Fixed Side Nozzles | 12pcs | 16pcs | 20pcs | 20pcs | |
| 铜管（前后模）吹气 Blowing Copper Tube In F/Moving Side | 12(∅6) | 16(∅6) | 20(∅6) | 20(∅6) | |
| 模组喷头（活动模）喷雾 Moving Side Nozzles | 12pcs | 16pcs | 20pcs | 20pcs | |
| 铜管吹气长度 Copper Tube Length | 60mm | ||||
| 行程 Stroke | X轴行程 X-Axis | 740mm | 1100mm | 1300mm | 1500mm |
| Y轴行程 Y-Axis | 1100mm | 1300mm | 1500mm | 1700mm | |
| 速度 Velocity | X轴速度 X-Axis | 1.1m/s | |||
| Y轴速度 Y-Axis | 1.0m/s | ||||
| 电机 Motor | X轴伺服电机 X-Axis | 1.0kw | |||
| Y轴伺服电机 Y-Axis | 2.0kw | ||||
| 上升/下降时间 Ascend+Descending Time | 1.3s | ||||
| 气压源 Compress Air | 5-6kgf/cm2 | ||||
| 气压源接口 Compress Air Inlet | 1-PT1 1/2" | 1-PT1 1/2" | 2-PT1 1/2" | 2-PT1 1/2" | |
| 离型剂 Release Agent | 大于气压源压力> compress air pressure | ||||
| 主电柜电源 Power Supplier | 三相四线AC380V (A、B、C、PE) Three phases with "N" & "PE" AC380V | ||||
| 操作电源 Operation Power Supplier | DC24 | ||||
| 机器重量 Net Weight | 540KG | 650KG | 1000KG | 1030KG | |
| 机器（长*宽*高）模组喷头 Dimensions(L*W*H) | 1670*850*2450 | 2300*950*2800 | 2520*960*2950 | 2700*960*3150 | |
