| 规格/机型 Specification/model | JSSR-1 | JSSR-2 | JSSR-3 | JSSR-4 | JSSR-6 |
|---|---|---|---|---|---|
| 适用压铸机 DCM | 150-200T | 280-400T | 500-630T | 700-800T | 900-1250T |
| 升降行程：安装面到钢管末端 Ascending/Descending Stroke | -620mm | -720mm | -870mm | -1020mm | -1220mm |
| 钢管（固定模） Copper Tuber On FP | 19pcs(?6) | 21pcs(?6) | 24pcs(?6) | 24pcs(?6) | 44pcs(?6) |
| 铜管（中间模） Copper Tuber On Mid | 18pcs (?6) | 20pcs (?6) | 23pcs (?6) | 23pcs (?6) | 30pcs (?6) |
| 铜管（活动模） Copper Tuber On MP | 19pcs (?6) | 21pcs (?6) | 24pcs (?6) | 24pcs (?6) | 44pcs (?6) |
| 气压源 Compress Air | 4.5-6.5kgf/cm2 | ||||
| 气压源接口 Compress Air Inlet | PT1 1" | PT1 1/4" | PT1 1/2" | ||
| 离型剂压力 Release Agent Pressure | 大于或等于气压源 ≥ compress air pressure | ||||
| 离型剂接口 Release Agent Inlet | PT 1/2" | PT 3/4" | |||
| 模厚调整范围 Die Height Range | 0~400m | 0~650mm | 0~880mm | ||
| 雾化器数 Atomizer | 2pcs | 3pcs | 4pcs | ||
| 喷雾头长度 Sprayer Head Length | 350mm | 420mm | 480mm | 440mm | |
| 铜管长度（短） Copper Tube(Short) | 470mm(56pcs) | 470mm(48pcs) | 570mm(55pcs) | 670mm(118pcs) | |
| 铜管长度（长） Copper Tube(Long) | 470mm(56pcs) | 570mm(14pcs) | 670mm(16pcs) | 670mm(118pcs) | |
| 底座行程 Base Stroke | 350mm | 350mm | 500mm | 500mm | 500mm |
| 气缸行程 Cylinder Stroke | 600mm | 700mm | 850mm | 1000mm | 1200mm |
| 上升时间 Ascending time | 1.3s~1.7s | 1.4s~1.8s | 1.6s~2.0s | 1.9s~2.3s | 2.1s~2.5s |
| 下降时间 Descending time | 1.0s~1.4s | 1.0s~1.4s | 1.3s~1.7s | 1.4s~1.8s | 1.6s~2.0s |
| 离型剂喷雾时间 Spraying Time | 固定模MAX9.9秒 & 活动模 MAX9.9秒 FP Max.9.9s & MP Max.9.9s | ||||
| 离型剂调水量 Release Agent Volume Adjustment | 固定模及活动模皆可调整水量大小 Available on FP and MP | ||||
| 主电柜电源 Main controller | 三相四线AC380V(A、B、C、PE) Three phases with "PE" AC380V | ||||
| 操作电源 Operating power supply | DC24V | ||||
| 裸机重量 Net Weight | 280KG | 300KG | 350KG | 355KG | 400KG |
| 机器外形尺寸（长*宽*高） Dimensions(L*W*H) | 1050*750*2000 | 1050*750*2000 | 1350*950*2500 | 1350*950*2500 | 1550*1050*2800 |
